CB628

Printer Control Board

CB628 Control Board

1. Control board to drive RT628

2. Item name: Control board to drive RT628

3. Item no.: CB628

4. Printing method: thermal

5. Paper width: 58mm

6. Printing width: 48mm

7. Resolution: 203dpi

8. Printing speed: up to 90mm/s

9. Barcode supported: I25, UPC-E, EAN-8, EAN-13, Codebar, Code39, Code93, Code128, Code11, MSI

10. Font: ASCII(12×24)

11. Graphic printing: direct bitmap printing

12. Communication interface: RS232 or TTL

13. Power supply: 5V-9V
